The AWSF142 Integrated Water Softener & Filtration System is a complete whole-house water treatment solution that combines high-capacity water softening technology with advanced activated carbon filtration in one powerful system.

Designed for modern homes requiring both soft water protection and cleaner, better-tasting water, the AWSF142 removes hardness minerals while reducing chlorine, odors, and organic contaminants throughout the entire home.

Powered by the ACF142 Digital Meter Control Valve, the system automatically monitors water usage and initiates regeneration only when needed, improving salt efficiency, reducing water waste, and providing reliable long-term performance.

With a 60,000 grain softening capacity, premium 10% cross-link resin, and high-quality activated carbon media, AWSF142 delivers exceptional performance for residential and light commercial applications.

Price starts at $3,300.00-

(Including standard installation labor and parts in the Greater Houston area. For a detailed quote and exact pricing, please contact us.)

Key Features & Benefits:

Integrated Softening & Filtration System

Combines whole-house water softening and activated carbon filtration into one complete solution, providing softer, cleaner, and better-quality water from every faucet.

60,000 Grain High-Capacity Softener

Provides powerful hardness removal capacity, helping prevent scale buildup on plumbing fixtures, water heaters, appliances, and household surfaces.

Premium 10% Cross-Link Resin

Uses high-performance 10% cross-linked resin designed for improved chlorine resistance, durability, and long service life compared with standard resin.

High Flow & Low Pressure Loss Design

Engineered with optimized internal flow paths and 1" connections to maintain strong water pressure even during multiple water usage periods.

Low Maintenance Long-Life Media

  • Softening resin: approximately 8–12 years under normal residential conditions
  • Activated carbon media: approximately 4–6 years depending on water quality and usage

High-Quality Activated Carbon Filtration

Premium carbon media reduces:

  • Chlorine taste and odor
  • Organic compounds (VOCs)
  • Unpleasant chemical smells
  • Sediment and impurities

Improves overall water taste and quality throughout the home.

Smart Digital Meter Control

Equipped with the ACF142 Digital Meter Control Valve, which measures actual water consumption and automatically controls regeneration based on demand.

Benefits:

  • Saves salt
  • Reduces wastewater
  • Improves system efficiency
  • Provides easy programming and monitoring



Specifications:

General:



  • Model: AWSF142
  • System Type: Whole House Water Softener + Carbon Filtration System
  • Application: Residential & Light Commercial
  • Installation: Point-of-entry whole-house treatment



Softening System:



  • Softener Capacity: 60,000 Grains
  • Resin Type: Premium 10% Cross-Link Cation Resin
  • Purpose:
    • Removes calcium and magnesium hardness
    • Helps reduce scale buildup
    • Protects plumbing and appliances



Filtration System:



  • Filter Media: Premium Activated Carbon
  • Carbon Capacity: Approx. 1.5 ft³
  • Removes / Reduces:
    • Chlorine
    • Odor
    • Organic contaminants
    • Chemical taste
    • Sediment particles



Control System:





Construction:



  • Media Tanks: Fiberglass-reinforced for durability and corrosion resistance
  • Brine Tank: Heavy-duty polyethylene
  • Bypass Valve: Included for easy isolation during service
  • Plumbing Ports: Standard 1-inch FNPT inlet/outlet; drain and brine ports with hose-barb fittings
  • Internal Risers/Distributors: High-flow, non-corrosive materials for consistent performance



Power and Installation:



  • Power Needs: 120 V outlet required for the F142 digital control
  • Installation: Whole-house, point-of-entry layout—indoors or protected area
  • Setup Time: Typically functional within 2-3 hours post-installation; includes plumbing, brine fill, and control setup



Certifications and Warranty:



  • Certifications: NSF/ANSI certified for performance and safety
  • Warranty: Typically includes a limited warranty on the tank, control valve, and filter media (duration may vary)(Check heck for details)

Features:



  • Integrated System: Combines softening, carbon filtration, and sediment removal in one streamlined solution
  • Salt-Based Softening: Reliable ion exchange method to prevent scale and preserve plumbing/appliance longevity
  • Digital Efficiency: F142 meter control ensures precise, demand-driven regeneration—boosting salt and water savings
  • Water Quality: Removes chemical odors and tastes, while maintaining optimal water flow throughout the home
  • Low-Maintenance Design: Long-lasting media, digitized operation, and accessible servicing components



Dimensions & Weight:



  • Softener Tank: 10" × 54" (~1.5 ft³ resin capacity)
  • Filter Tank: 10" × 54" (~1.5 ft³ activated carbon)
  • Brine Tank: ~18" × 33"
  • Overall Footprint: Approximately 38" × 18" when installed side-by-side
  • Installed Weight (media-filled): Around 150 lbs



Performance:



  • Hardness Capacity: Treats up to ~30 grains per gallon hardness
  • Flow Rate: Target 10–12 GPM for residential applications
  • Service & Backwash Flow: Backwash flow ~3 GPM at typical pressure
  • Water Pressure Tolerance: Operates between 22–87 PSI (0.15MPa-0.6MPa)
  • Temperature Range: 41–122°F (5–50°C)
  • Whole-Home Capability: Ideal for 3 to 5 bathroom dwellings



Maintenance:



  • Salt Refill: Every 6-10 weeks, depending on water hardness and household usage
  • 10% cross-linked resin (water softener): Typically lasts 8–12 years under normal residential use, or approximately 1,000,000–2,000,000 gallons of water throughput.
  • Carbon Media: Replace approximately every 4-6 years
  • Sediment Filters (if applicable): Replace every 6–12 months
  • Valve Service: Minimal; digital interface simplifies programming and diagnostics—no manual regeneration needed



Why Choose AWSF142?



  • Complete whole-house soft water + filtration solution

  • 60,000 grain high-capacity softening performance

  • Premium 10% resin for longer service life

  • High-quality activated carbon for better tasting water

  • Smart digital regeneration saves salt and water

  • Protects plumbing, appliances, skin, and hair

  • Ideal for residential and light commercial applications
