The AWSF142 Integrated Water Softener & Filtration System by Aqua Tech Texas is a next-generation, all-in-one whole-house water treatment solution that combines high-efficiency water softening with advanced chemical filtration. Designed for durability, performance, and simplicity, it delivers softened, clean, and great-tasting water to every tap in your home. Built around a new F142 digital metered control valve, this model brings together ease-of-use, performance, and durability for the modern home.

Price starts at $3,000.00-

(Including standard installation labor and parts in the Greater Houston area. For a detailed quote and exact pricing, please contact us.)

Dual System Integration



  • Combines both ion-exchange softening and chemical filtration into one setup for comprehensive water treatment.

  • Effectively removes calcium & magnesium (hardness), chlorine, and organic contaminants.





Built for Full-Home Usage



  • Designed to handle high-flow rates and household-level water demands.

  • Constructed with durable fiberglass tanks and industry-standard plumbing connections.




High Flow & Low Pressure Drop



  • Engineered to allow water to pass through with very little resistance, keeping your home’s water pressure strong and consistent.

  • Uses full-port 1" connections and streamlined internal pathways to reduce pressure loss, even during peak water usage.




Low Maintenance



  • Long media lifespan: carbon typically lasts    4 - 6 years; softening resin is highly durable.

  • Demand-based regeneration triggered by actual water usage (metered), optimizing salt and water efficiency




Specifications:

General:



  • Model: AWSF142

  • System Type: Salt-based, whole-house water softening + purification

  • Application: Residential homes, point-of-entry use

  • Water Treatment Goals:

    • Remove hardness (calcium & magnesium)

    • Reduce chlorine, odors, volatile organic compounds (VOCs), and other chemical contaminants

    • Filter out sediment for cleaner flow and better protection of plumbing/appliances



Control Features :



  • Control Valve: F142 digital metered control

  • Operation: Demand-based regeneration triggered by actual water usage (metered), optimizing salt and water efficiency

  • Display & Programming: Digital interface for easy setup, monitoring, and maintenance alerts (e.g., backwash, service reminder)

  • Power: Requires 120 V standard outlet



Construction:



  • Media Tanks: Fiberglass-reinforced for durability and corrosion resistance

  • Brine Tank: Heavy-duty polyethylene

  • Bypass Valve: Included for easy isolation during service

  • Plumbing Ports: Standard 1-inch FNPT inlet/outlet; drain and brine ports with hose-barb fittings

  • Internal Risers/Distributors: High-flow, non-corrosive materials for consistent performance



Power and Installation:



  • Power Needs: 120 V outlet required for the F142 digital control

  • Installation: Whole-house, point-of-entry layout—indoors or protected area

  • Setup Time: Typically functional within 2-3 hours post-installation; includes plumbing, brine fill, and control setup



Maintenance:



  • Salt Refill: Every 6-10 weeks, depending on water hardness and household usage

  • Carbon Media: Replace approximately every 4-6 years

  • Sediment Filters (if applicable): Replace every 6–12 months

  • Valve Service: Minimal; digital interface simplifies programming and diagnostics—no manual regeneration needed

Features:





  • Integrated System: Combines softening, carbon filtration, and sediment removal in one streamlined solution

  • Salt-Based Softening: Reliable ion exchange method to prevent scale and preserve plumbing/appliance longevity

  • Digital Efficiency: F142 meter control ensures precise, demand-driven regeneration—boosting salt and water savings

  • Water Quality: Removes chemical odors and tastes, while maintaining optimal water flow throughout the home

  • Low-Maintenance Design: Long-lasting media, digitized operation, and accessible servicing components






Dimensions & Weight:



  • Softener Tank: 10" × 54" (~1.5 ft³ resin capacity)

  • Filter Tank: 10" × 54" (~1.5 ft³ activated carbon)

  • Brine Tank: ~18" × 33"

  • Overall Footprint: Approximately 38" × 18" when installed side-by-side

  • Installed Weight (media-filled): Around 150 lbs



Performance:



  • Hardness Capacity: Treats up to ~30 grains per gallon hardness

  • Flow Rate: Target 10–12 GPM for residential applications

  • Service & Backwash Flow: Backwash flow ~3 GPM at typical pressure

  • Water Pressure Tolerance: Operates between 22–87 PSI (0.15MPa-0.6MPa)

  • Temperature Range: 41–122°F (5–50°C)

  • Whole-Home Capability: Ideal for 3 to 5 bathroom dwellings



Certifications and Warranty:



  • Certifications: NSF/ANSI certified for performance and safety
  • Warranty: Typically includes a limited warranty on the tank, control valve, and filter media (duration may vary)(Check heck for details)
